1. Economic and efficient: H Series Industrial Helical Gear Unit achieve a high level of transmission efficiency. It adopts advanced gear design and manufacturing process to maximize transmission efficiency. Compared with other transmission devices, H Series Industrial Helical Gear Unit have higher efficiency, can effectively reduce energy consumption, and significantly improve production efficiency and product quality.
2. Reliable and stable: H Series are made of high quality materials and precision manufacturing process, which ensures its high durability and reliable stability. Whether in high temperature, low temperature or harsh working conditions, H Series Industrial Helical Gear Unit can show excellent performance, ensuring the reliability and long-lasting stability of the equipment.
3. Low noise: They are designed and manufactured with full consideration of noise reduction factors. Through precise gear coordination and vibration damping design, H Series Industrial Helical Gear Unit have low noise during operation, providing quieter conditions for the working environment.
4. Easy installation and maintenance: The products are very easy to install and maintain. It adopts modular design, component replacement and maintenance are very easy. In addition, the overall structure of H Series Industrial Helical Gear Unit is compact, which reduces the floor space and improves the flexibility and layout effect of the equipment.
5. Wide adaptability: H Series Industrial Helical Gear Unit are suitable for different industrial fields, such as metallurgy, mining, construction, chemical industry and so on. Whether it is in the transmission of high torque heavy-duty equipment, or in the high-speed rotation of precision machinery, H series industrial gearboxes are able to play out its superior transmission performance to meet the needs of different industries.
1.Harbor and shipping
2.Hoist and transport
3.Electric power
4.Coal mining
5.Cement and construction
6.Paper and light industry
7.Chemical industry and environmental protection.Etc.
| Housing material | Cast iron/Ductile iron |
| Housing hardness | HBS190-240 |
| Gear material | 20CrMnTi alloy steel |
| Surface hardness of gears | HRC58°~62 ° |
| Gear core hardness | HRC33~40 |
| Input / Output shaft material | 42CrMo alloy steel |
| Input / Output shaft hardness | HRC25~30 |
| Machining precision of gears | Accurate grinding, 6~5 Grade |
| Lubricating oil | GB L-CKC220-460, Shell Omala220-460 |
| Heat treatment | Tempering, cementiting, quenching, etc. |
| Efficiency | 94%~96% (depends on the transmission stage) |
| Noise (MAX) | 60~68dB |
| Temp. Rise (MAX) | 40°C |
| Temp. Rise (Oil)(MAX) | 50°C |
| Vibration | ≤20µm |
| Backlash | ≤20Arcmin |
| Brand of bearings | China top brand bearing, HRB/LYC/ZWZ/C&U.Or other brands requested, SKF, FAG, INA, NSK. |
| Brand of oil seal | NAK --- Taiwan or other brands requested |
