Absolute flexibility is achieved by the wide choice of mounting options, shaft configurations and motor interfaces, all offered as standard.VF Series can be completed trough the selection of a wide range of electric motor entirely, Asynchronous-motors, both IEC and compact can be coupled with VF Series providing to our customers a complete drive solution. Looking for an Enhanced Protection gear reducer suitable for Food&Beverage,packing Chemical and Pharma industries as well as for harsh environment?
| Name: | Small size worm gear reducer |
| Model: | VF030, 040, 050, 063, 075, 090, 105, 110, 130, 150 |
| Ratio: | 1:5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80, 100 |
| Color: | Blue, Silver, other. |
| Noise: | low noise (<50 dB) |
| Material: | Housing: Die-Cast Aluminum Alloy |
| Worm Gear-Bronze 9-4# | |
| Worm-20CrMn Ti with carburizing and quenching, the surface hardness is 56-62HRC | |
| Shaft-chromium steel-45# | |
| Packing: | Carton and Wooden Case |
| Bearing: | C&U Bearing |
| Seal: | NAK SKF |
| Certificate: | ISO9001, CE, 3C |
| Warranty: | 12 months |
| Input Power: | 0.06kw, 0.09kw, 0.12kw, 0.18kw, 0.25kw, 0.37kw, 0.55kw, 0.75kw, 1.1kw, 1.5kw, 2.2kw, 3kw, 4kw |
| IEC Flange: | 56B5, 56B14, 63B5, 63B14, 71B5, 71B14, 80B5, 80B14, 90B5, 90B14, 100B5, 100B14, 112B5, 112B14 |
| Lubricant: | Synthetic & Mineral |
1. Aluminum alloy housing
2. High-quality bearings prevent leaks, contribute to flexibility in mounting, and increase reducer life
3. NEMA and IEC motors inputs
4. Double-lip oil seals
5. O-rings are used to prevent leaks
6. Standard hollow output bore and optional plug-in shafts provide greater flexibility.
7. Automated manufacturing process from an ISO 9001 certified company assures quality, reliable gearing.
1. Made of high-quality aluminum alloy, light in weight and non-rusting
2. Large in output torque
3. Smooth in running and low in noise, can work a long time in dreadful conditions
4. High in radiating efficiency
5. Good looking in appearance, durable in service life, and small in volume
6. Suitable for Omnibearing installation
Industrial Machine: Food Stuff, Ceramics, Chemical, Packing, Dyeing, Woodworking, Glass, etc.
