The strength of our helical-worm gear units lies in their simple mechanical design, making them more efficient than plain worm gear units.
S series gear units also run smoothly in operation.
1. High modular design, biomimetic surface with owned intellectual property right.
2. Adopt German worm hob to process the worm wheel.
3. Spiral worm gear design improves transmission efficiency.
4. The spiral worm gear meshes smoothly, low running noise.
5. The use of high-quality materials and precision processing to ensure long service life.
6. Reasonable structural design, easy for daily maintenance and repair.
7. Can achieve the direct combination for two sets of gearbox.
8. Mounting mode: foot mounted, flange mounted, torque arm mounted.
9. Output shaft: solid shaft, hollow shaft.
1.Chemical industry and environmental protection
2.Metal processing
3.Building and construction
4.Agriculture and food
5.Textile and leather
6.Forest and paper
7.Car washing machinery
| Housing material | Cast iron/Ductile iron |
| Housing hardness | HBS190-240 |
| Gear material | 20CrMnTi alloy steel |
| Surface hardness of gears | HRC58°~62 ° |
| Gear core hardness | HRC33~40 |
| Input / Output shaft material | 42CrMo alloy steel |
| Input / Output shaft hardness | HRC25~30 |
| Machining precision of gears | Accurate grinding, 6~5 Grade |
| Lubricating oil | GB L-CKC220-460, Shell Omala220-460 |
| Heat treatment | Tempering, cementiting, quenching, etc. |
| Efficiency | 94%~96% (depends on the transmission stage) |
| Noise (MAX) | 60~68dB |
