HXG Series Shaft Mounted Gear Reducer is a shaft mounted gear reducer is which can be optionally fitted with an anti-runback device except for HXG30.
It is wildly used in mechanical transmission fields such as agriculture, telecommunications industry, food industry, tobacco industry, automotive industry, cement industry, mining industry, tourism industry and so on.
The HXG Series Shaft Mounted Gear Reducer has long has long been established as a best seller for quarry and mine applications where absolute reliability and low maintenance are key factors. Another winning factor is the backstop option that prevents back driving in the case of inclined conveyors. This gearbox can be completed by selecting from a wide range of electric motors entirely manufactured by HEMU.
Kinds of mining
Cement and construction
Electric power
Industrial agitators
Paper and light industry
| HEMU Hxg Series Shaft Mounted Hanging Gear Speed Reducer | |||||
| Type | Ratio | Model | Standard bore (mm) | Rated power(KW) | Rated torque(N.m) |
| HXG series |
5; 7; 10; 12.5; 15; 20; 25; 31 |
HXG30 | 30 | 3 | 180 |
| HXG35 | 35 | 5.5 | 420 | ||
| HXG40 | 40; 45 | 15 | 950 | ||
| HXG45 | 45; 50; 55 | 22.5 | 1400 | ||
| HXG50 | 50; 55; 60 | 37 | 2300 | ||
| HXG60 | 60; 65; 70 | 55 | 3600 | ||
| HXG70 | 70; 85; | 78 | 5100 | ||
| HXG80 | 80; 100 | 110 | 7000 | ||
| HXG100 | 100; 120 | 160 | 11000 | ||
| HXG125 | 125; 135 | 200 | 17000 | ||
