The compact construction as a planetary gear unit and a primary gear unit is a feature of our industrial gear unit P series.
They are used in systems which demand low speeds and a high torque.
With its high efficiency, compactness and reliability, the P Series Industrial Bevel Planetary Gear Unit is the ideal choice for industrial drives. Correct selection and maintenance can further extend their service life and ensure the efficient operation of equipment.
1.With low energy loss, it is suitable for high power and high torque application scenarios.
2.Modularized design for easy integration with other equipment.
3.Multiple planetary wheels share the load at the same time, which improves the load carrying capacity and is suitable for heavy-duty working conditions.
4.It is suitable for equipments that require high running smoothness.
5.The key components are made of high quality materials, which are wear-resistant, corrosion-resistant and have a long service life.
6.Flexible installation, easy to integrate into the existing system.
1.Harbor and shipping
2.Hoist and transport
3.Electric power
4.Coal mining
5.Cement and construction
6.Paper and light industry
7.Chemical industry and environmental protection.Etc.
| Housing material | Cast iron/Ductile iron |
| Housing hardness | HBS190-240 |
| Gear material | 20CrMnTi alloy steel |
| Surface hardness of gears | HRC58°~62 ° |
| Gear core hardness | HRC33~40 |
| Input / Output shaft material | 42CrMo alloy steel |
| Input / Output shaft hardness | HRC25~30 |
| Machining precision of gears | Accurate grinding, 6~5 Grade |
| Lubricating oil | GB L-CKC220-460, Shell Omala220-460 |
| Heat treatment | Tempering, cementiting, quenching, etc. |
| Efficiency | 94%~96% (depends on the transmission stage) |
| Noise (MAX) | 60~68dB |
| Temp. Rise (MAX) | 40°C |
| Temp. Rise (Oil)(MAX) | 50°C |
| Vibration | ≤20µm |
| Backlash | ≤20Arcmin |
| Brand of bearings | China top brand bearing, HRB/LYC/ZWZ/C&U.Or other brands requested, SKF, FAG, INA, NSK. |
| Brand of oil seal | NAK --- Taiwan or other brands requested |
