The compact construction as a planetary gear unit and a primary gear unit is a feature of our industrial gear unit P series.
They are used in systems which demand low speeds and a high torque.
P Series Industrial Parallel Shaft Planetary Gear Unit is a transmission device that combines planetary gearing with a parallel shaft design. The planetary gearing shares the load by engaging multiple planetary wheels simultaneously, resulting in high torque output and high transmission efficiency. The parallel shaft design allows for a more compact structure and is suitable for space-constrained application scenarios.
1.The planetary gear drive shares the load through multiple planetary wheels meshing at the same time, resulting in high transmission efficiency.
2.Parallel shaft design makes the overall structure more compact and saves installation space.
3.The gears are made of high-strength alloy steel, precision machined and heat-treated, with excellent anti-wear and anti-impact performance.
4.Planetary gear transmission through a number of planetary wheels meshing at the same time, reducing vibration and impact, running more smoothly.
5.Excellent sealing performance prevents lubricant leakage and external pollutants from entering.
1.Harbor and shipping
2.Hoist and transport
3.Electric power
4.Coal mining
5.Cement and construction
6.Paper and light industry
7.Chemical industry and environmental protection.Etc.
| Housing material | Cast iron/Ductile iron |
| Housing hardness | HBS190-240 |
| Gear material | 20CrMnTi alloy steel |
| Surface hardness of gears | HRC58°~62 ° |
| Gear core hardness | HRC33~40 |
| Input / Output shaft material | 42CrMo alloy steel |
| Input / Output shaft hardness | HRC25~30 |
| Machining precision of gears | Accurate grinding, 6~5 Grade |
| Lubricating oil | GB L-CKC220-460, Shell Omala220-460 |
| Heat treatment | Tempering, cementiting, quenching, etc. |
| Efficiency | 94%~96% (depends on the transmission stage) |
| Noise (MAX) | 60~68dB |
| Temp. Rise (MAX) | 40°C |
| Temp. Rise (Oil)(MAX) | 50°C |
| Vibration | ≤20µm |
| Backlash | ≤20Arcmin |
| Brand of bearings | China top brand bearing, HRB/LYC/ZWZ/C&U.Or other brands requested, SKF, FAG, INA, NSK. |
| Brand of oil seal | NAK --- Taiwan or other brands requested |
