Palm Oil Mill Gear Reducer

In the Palm Oil press, the Palm Oil Mill Gear Reducer is mainly used to drive the rotation of the screw to ensure the normal output of the palm. The screw press plays a role in squeezing Palm fruits in the Oil press. Through the deceleration and torsion increase functions of the Palm Oil Mill Gear Reducer, the screw press can squeeze palm fruits at an appropriate speed and force, thereby extracting the oil. The use of Palm Oil Mill Gear Reducer mainly makes the Oil press run more smoothly, improves pressing efficiency and oil output rate ‌ The maintenance of Palm Oil Mill Gear Reducer is very convenient and can greatly save maintenance costs.

Introduction:

Model : M3PLF50HM
Ratio : 56
Torque : 44600 Nm
Output Speed : 27 Rpm
Mechanical Power Rating : 117 kW
(at 1500 rpm input)

Advantages:

Output Shaft: 42CrMo
Helical Gears and Pinions:18CrNiMo7-6
Housing:HT250
Branded Bearings: NSK
Sealing System:Dust-Proof Regreasable (Standard for POM)
