SS304 stainless steel NMRV worm reducer

SS304 stainless steel NMRV worm reducer

In the current industrial transmission field, SS304 stainless steel NMRV worm reducer has become a cutting-edge solution to meet the market's demand for high performance and flexible configurations due to its excellent performance. It is worth mentioning that the newly launched NMRV Power series has been innovatively upgraded from its traditional strengths by offering a compact integrated helical/worm construction option. The series adopts a modular design concept and achieves wide adaptability by streamlining the base model to cover a wide range of application scenarios at various power levels. With its excellent performance, it supports a wide range of reduction ratios from 5 to 1,000, which fully meets the drive requirements under different working conditions. This design not only enhances the versatility of the product, but also ensures that optimal transmission efficiency can be realized in various application environments.

SS304 stainless steel NMRV worm reducer is made of high quality SS304 stainless steel material, which is characterized by wear resistance, pressure resistance, corrosion resistance, etc., and is well known for its stable and reliable working performance. Precision processing technology and strict quality control ensure the accuracy and reliability of the product.

Advantages:

1. Adopting advanced modularized architecture design, realizing flexible configuration and fast assembly, significantly improving product adaptability.

2. It has excellent load bearing performance, ensures smooth and reliable power transmission, and the noise control is at the leading level in the industry.

3. Equipped with precision sealing system to effectively prevent media leakage, which can be widely used in various industrial scenarios.

4. Optimize transmission efficiency, significantly reduce energy consumption, and achieve energy-saving and environmentally friendly operation.

5. The overall design focuses on economy, reducing the initial investment at the same time, significantly reducing the later maintenance costs.

SS304 stainless steel NMRV worm reducer:

1. Housing:

Die-cast Aluminium Alloy Gearbox (RV025~RV090)Cast Iron Gearbox (RV110~RV150)

2. Worm Wheel:

Wearable Tin Bronze Alloy, Aluminum Bronze Alloy

3. Worm Shaft:

20Cr Steel, carburizing, quenching, grinding, surface hardness 56-62HRC, 0.3-0.5mm remaining carburized layer after precise grinding

4. Input Configurations:

Equipped with Electric Motors (AC Motor, Brake Motor, DC Motor, Servo Motor)
IEC-normalized Motor Flange
Solid Shaft Input
Worm Shaft Tail Extension Input

5. Output Configurations:

Keyed Hollow Shaft Output
Hollow Shaft with Output Flange
Plug-in Solid Shaft Output

6. Spare Parts:

Worm Shaft Tail Extension, Single Output Shaft, Double Output Shaft, Output Flange, Torque Arm, Dust Cover

7. Gearbox Painting:

Aluminium Alloy Gearbox:
After Shot Blasting, Anticorrosion Treatment and Phosphating, Paint with the Color of RAL 5010 Gentian Blue or RAL 7035 Light Grey
Cast Iron Gearbox:
After Painting with Red Antirust Paint, Paint with the Color of RAL 5010 Gentian Blue

SS304 stainless steel NMRV worm reducer Models:

Hollow Shaft Input with IEC-normalized Motor Flange
RV025~RV150
Solid Shaft Input
RV025~RV150

Features:

1. Quality aluminum alloy gear box, light weight and not rust
2. 2 optional worm wheel materials: Tin bronze or aluminum bronze alloy
3. Standard parts and very flexible for shaft configurations and motor flange interface
4. Several optional mounting options
5. Low noise, High efficiency in heat dissipation

Technical Data:

Ratio:

5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80, 100

Installation:

Flange Mounted
Foot Mounted
Torque Arm Mounted

Lubrication:

Grease Lubrication
Oil-bath and Splash Lubrication

Cooling:

Natural Cooling
